What Does a Thermal Imaging Camera Actually Show During a Termite Inspection?

Thermal imaging cameras get mentioned a lot in pest control advertising. They're listed as a feature, used as a selling point, and sometimes described as if they're a magic capability that other inspectors don't have. The reality is more useful — and more honest — than that.

Here's what a thermal imaging camera actually does during a termite inspection, what it surfaces that a visual check can't, and what it doesn't do.

How thermal imaging works — in plain English

A thermal imaging camera reads surface temperature. It doesn't see through walls; it reads the temperature differential across surfaces. Different materials at different moisture levels emit different amounts of infrared radiation. The camera translates these differences into colour gradients on a display — warmer areas in one colour, cooler areas in another.

The reason this is useful in a termite or timber-pest inspection is that moisture changes surface temperature. Wet material — wet plaster, damp timber, a wall cavity with a slow leak behind it — is cooler relative to the surrounding dry material. That temperature difference shows up as a distinct patch on the thermal display.

Termite activity in timber can also create a thermal signature. Active termite workings generate metabolic heat in the timber, and the humidity inside galleries changes the thermal behaviour of the wall surface above them. The signature isn't universal — conditions need to be right, and the activity needs to be at a certain density — but it's detectable.

What thermal imaging actually surfaces

Moisture behind plaster you can't see. A slow leak in a wall cavity — from a plumbing joint, a cracked render, a failed wet-area seal — can be active for months without appearing on the surface. On a thermal image, the cool patch from the moisture is visible. It directs the inspector's attention and physical investigation to the right location rather than leaving a hidden condition undetected.

Termite activity in timber. When conditions are right — the right temperature differential between inside and outside, sufficient activity density — termite workings in timber produce a recognisable thermal pattern. The area of the wall over an active gallery reads differently from the surrounding timber. This is not a guarantee — a small or dormant colony may not produce a clear thermal signature — but active infestations in accessible wall framing are often detectable through this mechanism.

Roof and subfloor moisture from concealed leaks. Slipped tiles, cracked ridge capping, and failed valley flashings allow water into the roof void. The thermal camera picks up the cooler moisture zone in the roof framing even when the leak isn't yet visible from below. In subfloor spaces, moisture-affected bearers and joists show differently from dry timber.

Insulation displacement and void spaces. Insulation gaps and unexpected void spaces change the thermal response of wall and ceiling surfaces. Not a termite-specific finding, but useful context for understanding where a wall cavity is more exposed than expected.

What thermal imaging doesn't do

It doesn't see termites. This matters. A thermal camera doesn't produce an image of insects inside timber. It reads surface temperature patterns that are consistent with — or inconsistent with — the conditions associated with termite activity or moisture damage. The interpretation of those patterns is the inspector's job.

It doesn't replace physical inspection. Thermal imaging is a directional tool. It says "look here" — it doesn't say "here is the diagnosis." A thermal anomaly on a wall surface tells the inspector where to focus physical probing, moisture meter readings, and further investigation. It's a first-pass tool that makes the physical inspection more efficient and more thorough, not a substitute for it.

It's subject to conditions. Temperature differential is required for thermal imaging to work well. On a mild day where external and internal temperatures are very close, the contrast that makes moisture and termite signatures visible is reduced. The camera reads more clearly when there's a meaningful temperature differential — in the cooler months or early morning on a hot day. A skilled inspector knows this and manages it.

Why AS 3660.2 calls it "Additional"

AS 3660.2:2017 defines thermal imaging as an Additional Test — recommended, not mandated. Additional Tests (which also include moisture meter readings, radar units, and termite detection dogs) are recommended by the Standard when high moisture is detected without an obvious cause, or when termite activity is suspected but not yet confirmed visually.

"Additional" doesn't mean optional in any meaningful sense for a thorough inspection — it means the Standard recognises that not every inspection warrants every tool, and defines the threshold for when these tools are appropriate. In practice, on any pre-purchase or annual inspection where there's a reason to look — and in Sydney's older housing stock, there usually is — a thermal camera and moisture meter together close the gap between what a visual-only check can reach and what's actually there.

Both come on every inspection here. Not as an upcharge. Not as a premium tier. As part of how the job gets done properly.

I bring the thermal camera on every inspection because it tells me where to look. It doesn't tell me what's there — that's still my job.
